Cummins KTA19-M
KDV hariç fiyat
3
Favori
Share
Aramayı kaydetYazdır
BILGI
Ürün grubu
Deniz motoru üniteleri
Marka / model
Cummins KTA19-M
Kayıt yılı
2017
Durum
New/unused
Makinenin yeri
Jining
Ülke
Çin
Genel durum düzeyi
1
2
3
4
5
Mascus ID
4D583148
FIYATLANDIRMA
Para birimi seç
AYRINTILAR
Brüt ağırlık
1.814 kilogram
Motor
KTA19-M
Taşıma Ölçüleri (EnxBoyxYükseklik)
1666000 x 874000 x 1377000 mm
Motor gücü
373 kW (507 hp)
Emisyon sınıfı
Stage II / Tier II
Production country
A.B.D.
Delivery terms
FOB, CFR, CIF, EXW
Belgeler
Diğer bilgiler
Engine model KTA19-M(500HP)
Engine type 6 Cylinders in Line
Displacement 19 L
Rated Power (KW@RPM) 373 kW/500HP @ 1800rpm
Max.Torque/Speed 2077 N.m @ 1500 rpm
Rating Type Continuous
Cummins diesel engine KTA19-M(500HP) Technique Specification
Bore*stroke 159mm * 159mm
Intake method TurboCharged & Intercooled
Fuel systeme PT Pump
Cooling method Fluid Cooling
Governor Type Mechanical Control
Compression Ratio 15.5:1
Idel Speed 675-775 rpm
Starting System Electrical Starting Motor 12V/24V
Lowest Starting Temp .(without auxiliary system) -12℃
Cummins diesel engine KTA19-M(500HP) Trade Information
Engine Size(L*W*H): 1666mm*874mm*1377mm
Weight net 1814 Kg
Delivary time 25 working days
Jining Haoduo Import and export co., Ltd.
Second floor, First section, No.2 building,Jining Lantian Boiler 272000 Jining 济宁 Shandong 山东 Çin
