BILGI

Ürün grubu
Yol-Arazi Tipi Vinçler (AT)
Marka / model
Sany STC 700 T5
Kayıt yılı
2021
Kullanım saati
3.849 h
Ülke
Çin
Genel durum düzeyi
1
2
3
4
5
Mascus ID
9E175F05

FIYATLANDIRMA

Para birimi seç

AYRINTILAR

Stok no.
1
Son ekspertiz
2025-11-19
Üretici seri no.
1
Önceki sahiplerin sayısı
1
Brüt ağırlık
44.870 kilogram
Kaldırma kapasitesi
70.000 kilogram
Kayıt no.
1
Kolun son noktasında maksimum kaldırma kapasitesi
70.000 kilogram
Min. bom uzunluğu
300 santimetre
Emisyon sınıfı
Stage V / Tier V
Bom uzunluğu
1.600 santimetre
Min. orsalı vinç kolu
300 santimetre
Luffing jib
1.500 santimetre
Vinç kol uzunluğu
1.500 santimetre
Kaldırma yüksekliği
7.650 santimetre
Vinç kanca yüksekliği – yatay kol
1.500 santimetre
Vinç kanca yüksekliği – kaldırılmış kol
1.400 santimetre
Upper engine
Benz
Upper hours
857 h
Crane type
Hidrolik vinç
Orijinal renk
Original
Counterweight
14,000KG
Carrier engine
25,000KG
Motor üreticisi
CUMMINS
Taşıma Ölçüleri (EnxBoyxYükseklik)
14830 x 2800 x 3860 mm
Taşıyıcı tipi
Lastikli
Garanti
Good
Lastik markası
Michelin
Kalan ön lastikler / şasi
100
Mevcut arka lastikler
0
Production country
Çin
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Ataşmanlar
Fly Jib Hook Counter Weight We're from Shanghai Jipan Trade Co.,Ltd.I'm the Sales Manager, specializing in selling used machines from various brands, including excavators,truck cranes,crawler cranes,and so on.With extensive export experience, our machines are sold well in Europe, America, Africa,and other regions, receiving rave reviews and a high repurchase rate. We uphold the principles of integrity and quality, and have a professional service team to provide you with one-stop service, ensuring accurate, efficient, and safe delivery of your machines.We are committed to building long-term relationships with every customer from around the world with competitive prices and superior quality. Contact: Jason WhatsApp/Mobile:0086 13675656717 WeChat:+86 13675656717 Shipping Method:Container Vessel, Bulk Carrier, Flatbed Vessel, or RoRo Vessel.
Aksesuarlar
Kanca blokları
Diğer bilgiler
Performance parameters Maximum lifting height:76.5 meters Maximum lifting moment: 3146kN·m Maximum lifting capacity:70 tons The maximum single-rope speed of the main hoist is 130m/min Full extension/retraction time of the boom:125/140s Full boom lift/lower time:60/90 seconds Maximum rotational speed:1.7r/min Weight parameter The total weight of the whole machine is 47,300 kg Maximum counterweight:15 tons Size parameter The total length of the entire machine is 14,970mm The total width of the whole machine is 2800mm The total height of the whole machine is 3880mm Outrigger span (horizontal x vertical):8(5.27)×6.48m Dynamic parameters Engine model: CUMMINS Maximum power of the engine:276/1900kW/rpm The maximum output torque of the engine:1785/1000-1400N·m/rpm Driving parameters Maximum driving speed:90km/h Minimum turning radius:12 meters Maximum slope:0.45 Approach Angle:≥17° Departure Angle:≥13°

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 Shanghai 上海 Çin
