Cummins 4BTA3.9-G2
KDV hariç fiyat
7
Favori
Share
Aramayı kaydetYazdır
BILGI
Ürün grubu
Motorlar
Marka / model
Cummins 4BTA3.9-G2
Kayıt yılı
2018
Durum
New/unused
Makinenin yeri
Jining, Shandong, China
Ülke
Çin
Genel durum düzeyi
1
2
3
4
5
Mascus ID
7913B567
FIYATLANDIRMA
Para birimi seç
AYRINTILAR
Stok no.
4BTA3.9-G2
Son ekspertiz
yes
Motor gücü
75,0 kW (102 hp)
Part ID
4BTA3.9-G2
Servis geçmişi
Evet
Üretici seri no.
4BTA3.9-G2
Taşıma Ağırlığı
350 kilogram
Taşıma Ölçüleri (EnxBoyxYükseklik)
1100000 x 900000 x 1400000 mm
RPM
1500
Emisyon sınıfı
Stage II / Tier II
Garanti
ISO9001
Production country
Çin
Delivery terms
FCA, CPT, FOB, CFR, CIF, EXW
Diğer bilgiler
Cummins 4BTA3.9-G2 G-Drive Diesel Engine
General Information
Engine Model 4BTA3.9-G2
Engine Type 4 Cylinders in Line
Displacement 3.9 L
Bore*Stroke(mm) 102 * 120
CPL Number PP L006
Net Weight (with flywleel & alternator) 350 Kg
Overall Diemension(L*W*H) 867mm*544mm*988mm
Technical Specification
Fuel System BYC A Pump/GAC Electronic Governor
Aspiration Turbocharged & Intercooled
Governing Rate ≤5%
Electrical System(Starter Motor/Alternator) 12V/24V
Lowest Starting Temp without auxiliary system -12℃
Engine Cooling Fluid Volume 7.9 L
Performance Data
Rated Power/Speed 76kW/102HP @ 1500 rpm
Torque @ Rated Power 318 N.m @ 1500 rpm
Standby Power/Speed 83kW/111 HP @ 1500 rpm
Torque @ Standby Power 350 N.m @ 1500 rpm
Fuel Consumption @ Rated Power 213g/Kw.h
Fuel Consumption @ Standby Power 212g/Kw.h
Idel Speed 950 – 1050 rpm
Jining Haoduo Import and export co., Ltd.
Second floor, First section, No.2 building,Jining Lantian Boiler 272000 Jining 济宁 Shandong 山东 Çin
