Cummins QSB4.5-C130
KDV hariç fiyat
10
Favori
Share
Aramayı kaydetYazdır
BILGI
Ürün grubu
Motorlar
Marka / model
Cummins QSB4.5-C130
Kayıt yılı
2018
Durum
New/unused
Makinenin yeri
Jining, Shandong, China
Ülke
Çin
Genel durum düzeyi
1
2
3
4
5
Mascus ID
9F478951
FIYATLANDIRMA
Para birimi seç
AYRINTILAR
Stok no.
QSB4.5-C130
Son ekspertiz
yes
Motor gücü
97 kW (132 hp)
Part ID
QSB4.5-C130
Servis geçmişi
Evet
Üretici seri no.
QSB4.5-C130
Taşıma Ağırlığı
380 kilogram
Taşıma Ölçüleri (EnxBoyxYükseklik)
900 x 750 x 1050 mm
RPM
2200
Emisyon sınıfı
Stage IIIB / Tier IV interim
Garanti
ISO9001
Production country
Çin
Delivery terms
FCA, CPT, FOB, CFR, CIF, EXW
Diğer bilgiler
Cummins QSB4.5-C130 Diesel Engine for Industrial
General Information of Cummins QSB4.5-C130 Diesel Engine for Industrial
Engine Model QSB4.5-C130
Engine Type 4 Cylinders in Line
Displacement 4.5 L
Bore*Stroke(mm) 107 * 124
Compression Ratio 17.3:1
CPL Number 8754
Net Weight (with flywleel & alternator) 338 Kg
Overall Diemension(L*W*H) 777mm*632mm*901mm
Technical Specification of Cummins QSB4.5-C130Diesel Engine for Industrial
Certification Euro III
Aspiration Turbocharged & Intercooled
Fuel System Wuxi weihu Pump
Electrical System(Starter Motor/Alternator) 12V/500A; 24V/250A
Lowest Starting Temp.(with/without auxiliary system) -12℃/-24℃
Engine Cooling Fluid Volume 7.0 L
Performance Data of Cummins QSB4.5-C130Diesel Engine for Industrial
Rated Power/Speed 97kW/130HP @ 2200rpm
Max.Torque/Speed 600 N.m @ 1500 rpm
Fuel Consumption @ Rated Power 29 l/hr
Idel Speed 750 rpm
Max. Continuous Running Altitude 2000 m
Jining Haoduo Import and export co., Ltd.
Second floor, First section, No.2 building,Jining Lantian Boiler 272000 Jining 济宁 Shandong 山东 Çin
10
