Volvo EC 210
KDV hariç fiyat
Yazdır
BILGI
Ürün grubu
Paletli ekskavatörler
Marka / model
Volvo EC 210
Kayıt yılı
2023
Kullanım saati
952 h
Ülke
Çin
Genel durum düzeyi
1
2
3
4
5
Mascus ID
46ECDB1B
FIYATLANDIRMA
Para birimi seç
AYRINTILAR
Güç tipi
Dizel
Önceki sahiplerin sayısı
1
Son ekspertiz
2025-08-15
Araç altı durumu
98%
Motor
original
Brüt ağırlık
22.800 kilogram
Motor gücü
123 kW (167 hp)
Motor üreticisi
original
Emisyon sınıfı
Stage V / Tier V
Kepçe kapasitesi
0,52 m3
Track width
600 mm
Taşıma Ölçüleri (EnxBoyxYükseklik)
9745 x 2800 x 3080 mm
Orijinal renk
original
Garanti
1 year
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Ataşmanlar
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Nina
Whatsapp: +86 18055199047
Mobile:+86 18055199047
Wechat:18055199047
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs
Aksesuarlar
Klima
Izgaralı kepçe
Kumanda kolu kontrolü
Standart kazma kepçesi
Derinlik kontrolü
Diğer bilgiler
Specifications
Power Type: Conventional power
Manufacturer: Joint venture/Imported
Bucket Type: Backhoe
Tonnage (ton): 21
Operating Weight (kg): 18100 - 22800
Bucket Capacity (m³): 0.52 - 1.22
Boom Length (mm): 5700
Stick Length (mm): 2900
Performance
Swing Speed (rpm): 12.3
Swing Torque (Nm): 76.7
Travel Speed (km/h): 3.5 / 5.8
Bucket Digging Force (kN): 123
Stick Digging Force (kN): 96
Maximum Traction Force (kN): 183
Power System
Engine Model: Volvo D5E
Rated Power (kw/rpm): 123/2000
Maximum Torque (N.m): 670 / 1600
Displacement (L): 4.7
Number of Cylinders: 4
Bore × Stroke (mm): 108*130
Hydraulic System
Main Pump Type: Two variable displacement axial piston pumps
Pilot Pump Type: Gear pump
Maximum Flow of Main Pump (l/min): 2 x 212
Pilot Pump Flow (L/min): 1 x 18
Pilot Oil Circuit (MPa): 3.9
Working Hydraulic Circuit (Mpa): 32.4 / 34.3
Travel Hydraulic Circuit (Mpa): 34.3
Swing Hydraulic Circuit (Mpa): 27.9
Main Relief Setting Pressure (Mpa): 32.4 / 36.3
Boom Cylinder - Quantity × Bore × Stroke (mm): 2*125 x 1235
Stick Cylinder - Quantity × Bore × Stroke (mm): 1*135 x 1540
Bucket Cylinder - Quantity × Bore × Stroke (mm): 1*120 x 1065
Fluid Capacities
Fuel Tank (L): 375
Hydraulic Oil Tank (L): 160
Hydraulic System (L): 300
Engine Oil Change Capacity (L): 17
Coolant (L): 15
Dimensions
Overall Transport Length (mm): 9745
Overall Transport Width (mm): 2800
Overall Transport Height (mm): 3080
Overall Cab Height (mm): 2930
Upper Structure Width (mm): 2700
Track Ground Contact Length (mm): 3370
Total Track Length (mm): 4160
Track Shoe Width (mm): 600
Track Gauge (mm): 2200
Minimum Ground Clearance (mm): 460
Counterweight Ground Clearance (mm): 1025
Number of Track Rollers (per side): 7
Number of Top Rollers (per side): 2
Number of Track Shoes (per side): 46
Working Range
Maximum Digging Radius (mm): 9930
Maximum Digging Radius at Ground Level (mm): 9380
Maximum Digging Depth (mm): 6730
Maximum Digging Height (mm): 9220
Maximum Dumping Height (mm): 6430
Maximum Vertical Digging Depth (mm): 5620
