Bobcat S 530

S530 Skid-Steer Loader The Bobcat® S530, the smallest vertical-lift-path loader, is perfect for loading trucks or mixers where more reach and lift height are needed at the top of the lift cycle. The S530 is a popular choice in its size class. Horsepower 48.9 hp Rated Operating Capacity (ISO) 869 kg Operating Weight 2815 kg Performance S530 Skid-Steer Loader Emissions Tier (EPA) iT4 Loader Series M-Series Rated Operating Capacity (ROC) (ISO 14397-1) 869 kg Tipping Load (ISO 14397-1) 1737 kg Height to Hinge Pin 3023 mm Lift Arm Path Vertical Size and Speed S530 Skid-Steer Loader Operating Weight 2815 kg Bucket Width 1727 mm Cab Height 1972 mm Travel Speed – Low Range 11.8 km/h Travel Speed – High Range (Optional 2-Speed Travel) 17.3 km/h Engine S530 Skid-Steer Loader Horsepower 48.9 hp Type Natural Aspirated Fuel Tank Capacity 93.7 l Tires S530 Skid-Steer Loader Bobcat Standard Duty - Bobcat Heavy Duty Standard Bobcat Severe Duty Optional Bobcat Super Float Optional Control Options S530 Skid-Steer Loader Bobcat Standard (Foot Pedals/Steering Levers) Standard Selectable Joystick Control (SJC) Optional Radio Remote Control (SJC Required) Optional Machine Features S530 Skid-Steer Loader Air Ride Seat - Back-up Alarm & Horn Standard Bobcat Interlock Control System (BICSTM) Standard Cab with Heat Optional Cab with Heat & Air Conditioning - Deluxe Instrumentation (Includes Keyless Start) Optional Hydraulic Bucket Positioning Optional Front and Rear Work Lights Standard Radio Optional Ride Control Optional ROPS/FOPS Approved Cab Structure Standard Sound Reduction Package Optional 2-Speed Optional Features for Attachments S530 Skid-Steer Loader Attachment Control Kit Optional Bob-Tach Mounting System Standard Power Bob-Tach System Optional Fingertip Auxiliary Hydraulics Control Standard Hydraulic System Pressure 238-245 Bar Hydraulic Standard Flow 64.1 l/min Hydraulic High Flow (Optional) - Pressure Release Hydraulic Quick Couplers (Drain port) Standard
