BIK FC-110

Name: BIK FC-110
Brand: BIK
SKU: 6A58B12B
Availability: InStock

KDV hariç fiyat

Talep Üzerine Fiyat

Favori

Aramayı kaydet

Yazdır

BILGI

Ürün grubu

Vinç parçalari

Marka / model

BIK FC-110

Kayıt yılı

2025

Durum

New/unused

Makinenin yeri

Milford, Massachusetts

Ülke

A.B.D.

Genel durum düzeyi

Mascus ID

6A58B12B

AYRINTILAR

Motor üreticisi

DETROIT

Production country

A.B.D.

Diğer bilgiler

BOOM DETAILS New – BIK “Form-Crane” Series FC- 110 By PM – 100 ton/m Folding Knuckle Boom with jib – 8+6 extensions – 110’ Horizontal Reach Main Boom Horizontal Capacity: 36,800 lb ... 16’ 20,000 lb ... 23’ 16,000 lb ... 33’ 1,000 lb ... 47’ 7,200 lb ... 67’ Jib Horizontal Capacity: 3,200 lb ... 76’ 2,600 lb ... 87’ 2,200 lb ... 100’ 2,000 lb ... 104’ 1,600 lb ... 110’ PM Power-Link connections at Main, Knuckle & Jib Cylinders, Dual Planetary Gear Motors & Continuous Boom Rotation Double pilot operated on slewing and pilot operated check valves on all cylinders, Extra function plumbed to boom tip w/Hyd rotator & T-hook 180 degree flip-up Hydraulic Extra Wide Main outriggers at pedestal – 28’ – 7” span – 360 degree full load chart stability Hydraulic Oil Cooler, high pressure return filter and min. 100 –gallon hyd aluminum oil tank with gate valves mounted at front under deck 7 – Section DANFOSS Proportional Control Valve at Top-Seat with Ladder Access – & SCANRECO Proportional Radio Remote Control PM – Power Tronic onboard load & function monitoring system, Digital Load Indicator at top seat & remote , electric/hyd overload protection Radio Remote Control includes: 2-batteries, in-cab charger, and back-up cord – 5 level turtle (micro) slow down mode Lifting winch on Main boom plumbed to the end of jib with proper load hook & down weights Installed END OF FRAME, with integral sub-frame, 3/8” front and centre -½” sheer plating at crane for maximized torsion strength DECK DETAILS New – 22’ x 102” Flat Deck: Steel headboard w/ 4 Side Wrap Winches Steel Checker plate Floor, winch bar and holder Integral 6” sub-frame and extension at rear as torque box for boom with all proper engineered sheer platting X-braces & support Removable sides to hold in cages 2-Deck access Ladders, reflectors, conspicuity tape, Mud-flaps, 8-Winches and tracks (sliding) under deck (deck to be built same as your truck). TRUCK DETAILS New – Western Star 49X TA Steer /Tridrive (5 Axles total): 109,000 lb GVWR Detroit Diesel 16L – 565 hp / 2,050 ft/lb torque, Engine Brake, Detroit 12 spd Automated Trans. Truck cab white (2) x 20,000 LB front tandem steer axles on Air Ride with 425 / 65R22.5 tires 69,000 LB Tridrive Rears on Hendrickson Primax Air Ride suspension with 54” spread between drives Double Frame Polished ALCOA AluminumWheels front and outer rear Polished dual Vertical Exhaust pipes Chrome Grille & Bumper 80 gallon alum fuel tank Truck Features Include: A/C, Tilt/Telescopic steering, high level Interior, AM/FM stereo Bluetooth, air driver’s seat, fixed passenger seat, cruise, heated mirrors, exterior S/S sun visor, 6 wheel lock-ups , power windows/locks, Air ride cab, dual roof mounted strobe lights, trailer air tow package, etc… Also Included : Auxiliary Extra-Wide hydraulic outriggers 23’ spread front mounted for 360 degree stability 1” Drawplate Plate at rear of truck frame Aluminum locking checker plate toolbox installed (4) PVC stabilizer pads – with holders (4 pcs) Fully enclosed cab with heat & access steps from bumper Back up camera with pass side blind sideDiğerlerini göster
